High Efficiency in All Load Ranges: Off-line Converter IC with Green Mode [STR6S161HXD]

Jul. 05, 2022

Product Category: ICs > Power Management ICs > Off-line Converters

We have newly started mass production of the STR6S161HXD, a PWM off-line converter IC in which a current mode PWM controller IC and a power MOSFET are integrated into a single package.
This IC allows your application to have high efficiency in all load ranges, with not only the burst oscillation operation that reduces power consumption in standby mode but also the green mode that enhances efficiency at light to medium loads.
In addition, the STR6S161HXD has two different AC input voltage protections — the high-voltage protection (HVP) and the brown-in/brown-out function — and helps you design a power supply safely operable even in an area with unstable input voltages. The built-in power MOSFET has a breakdown voltage of 700 V and ensures the avalanche energy capability.
Also, its new package with widened pins resulted in a 7% increase in heat dissipation.

Applications

・Large Home Appliance
・Small Home Appliance
    (e.g., Vacuum Cleaner, Kitchen Appliance)
・Small Adapter
・Battery Charger
・Auxiliary Power Supply for Industrial Equipment

▶STR6S161HXD Product Page
▶STR6S161HXD Promotion Sheet

Small-sized, High-voltage, 3-phase Motor Drivers for Automotive [SAM265M30AA1/50AA1]

Jun. 02, 2022

Product Category: Automotive ICs > Automotive Motor Drivers > Automotive High Voltage 3-phase Brushless DC Motor Drivers

We have recently begun mass production of small-sized, high-voltage, 3-phase motor drivers for automotive applications—SAM265M30AA1 and SAM265M50AA1.
The SAM2 series are 3-phase brushless motor drivers in which output transistors, pre-drive circuits, bootstrap diodes with current-limiting resistors, and a temperature-sensing thermistor are highly integrated.
Through the driver IC downsizing and high-density power chip mounting technologies, we succeeded in reducing the package size by ≥20% (compared to our old type ICs) with the same conventional devices included inside. Moreover, the SAM2 series offers the industry-leading* temperature-sensing accuracy and low-noise characteristics. (* Based on our survey as of May 1, 2022.) Your application will have a smaller PCB space, higher reliability, and more ease of designing high-voltage circuits.

Applications

3-phase motor drives for high-voltage auxiliary systems used in hybrid electric vehicles (HEV) and electric vehicles (EV), such as:
・Electric Compressor
・Electric Oil Pump etc.

▶SAM2 Series Special Page
▶SAM2 Series Promotion Sheet

Low-noise Fast Recovery Diodes [CTXR Series]

May 02, 2022

Product Category: Discretes>Diodes> Fast Recovery Diodes

CTXR series is low noise FRD with high switching characteristic. We offer a product lineup that includes devices with a breakdown voltage of up to 600 V, and a rated current of 20 A/60 A. Suitable for rectifier circuits such as PFC circuits for high-current applications.
Promotion Sheet

Features

• Low noise by turn-off ringing reduction
• Efficiency improvement by switching loss reduction
• Thermal runaway limit temperature improvement by H∙I_R reduction
• Bare Lead Frame: Pb-free (RoHS Compliant)

Applications

• PFC circuit (CCM)
• TV, Air conditioner

Ultra-high CRI LED Devices with Industry-leading Color Rendering Index (Ra, Ri) [SEP1A Series]

Apr. 06, 2022

Product Category: LEDs > Visible Light LEDs > Surface Mount Flat Type LEDs

The SEP1A series are high color rendering LED devices that have quality defined by not only the average color rendering index, Ra, but also the special color rendering index, Ri. By using our LEDs, you can realize lighting fixtures with the same performance as color rendering AAA fluorescent lamps for color evaluation. The SEP1A series, developed with our own color rendering improvement technology, can maintain the industry's highest luminous efficiency while achieving high color rendering. This leads to the energy-saving effect* over 2 times higher than color rendering AAA fluorescent lamps. Based on these advantages, the SEP1A series can also be used as a light source for lighting equipment which require high color rendering, such as task lighting and museums lighting. In addition, our LED devices suppress ultraviolet components and thus promise preventive effects against discoloration of exhibits.
* Energy-saving performance depends on the design of lighting equipment.

　　
Characteristics* and Features 　　

• Average color rendering index: Ra ≥ 95
• Special color rendering index: Ri ≥ 90 (i = 9 to 15)
• High luminous efficiency (142 lm/W)
• UV-suppressing, discoloration-preventive light

* When SEP1AQ1L92SS and SEP1AQ1L92LL are used in combination.

Selection Guide（Under Development） 　

High Voltage 3-phase BLDC Motor Driver with Temperature Sensing Function 【SIM6890M Series】
Added SIM6895M and SIM6897M as New Products

Mar. 07, 2022

Products： ICs > Motor Drivers> Hight Voltage 3-phase Brushless DC Motor Drivers

The SIM6890M series are high voltage 3-phase motor drivers in which transistors, pre-drive circuits,
and bootstrap circuits(diodes and resistors) are highly integrated. These products can optimally control
the inverter systems of low- to medium-capacity motors that require universal input standards.
We have added SIM6895M and SIM6897M to our SIM6890M lineups.SIM6897M holds IGBT as output element,
with Io=10A.SIM6895M holds IGBT as output element, with Io=5A and low noise function.

Remarks


Application

• Refrigerator Compressor Motor
• Fan Motor and Pump Motor for Washer and Dryer
• Fan Motor for Air Conditioner
• Fan Motor for Air Purifier

Lean more
SIM6891M
SIM6892M
SIM6893M
SIM6895M
SIM6896M
SIM6897M

Power ICs for PWM Off-line Switching Power Supply
[STR6A100xV/xVD Series]

Jan. 18, 2022

Product Category: ICs >Power Management ICs > Off-line Converters

The STR6A100xV/xVD series are power ICs for switching power supplies, incorporating a MOSFET and a current mode PWM controller IC. The operating mode of the IC automatically changes to green-mode or burst oscillation mode according to load in order to improve the all load efficiency. The product achieves high cost-performance power supply systems with few external components.
No Load Power Consumption < 15 mW,Soft Start Function,Adjustable Standby Operating Point.
We have expanded STR6A100xV/xVD series by adding STR6A153MVD to our product lineup. For more product information, please check the link below.



Application

• White Goods
• Office Automation Equipment
• Audio Visual Equipment
• Industrial Equipment
• Other Switched-Mode Power Supply

Lean more　
STR6A Sreis　
STR6A153MVD　
Green Mode(YouTube)　

High Voltage 3-Phase BLDC Motor Driver with Temperature Sensing Function
[SIM6890M Series]

Aug. 30, 2021

Products： ICs > Motor Drivers> Hight Voltage 3-phase Brushless DC Motor Drivers

The SIM6890M series are high voltage 3-phase motor drivers in which transistors, pre-drive circuits, and bootstrap circuits (diodes and resistors) are highly integrated. These products can optimally control the inverter systems of low- to medium-capacity motors that require universal input standards.

Remarks


Application

• Refrigerator Compressor Motor
• Fan Motor and Pump Motor for Washer and Dryer
• Fan Motor for Air Conditioner
• Fan Motor for Air Purifier

Lean more
SIM6891M
SIM6892M
SIM6893M
SIM6896M

Fully digital-controlled power supply IC【MD6752】 (incorporates a bridgeless PFC control circuit and an LLC current-resonant circuit）

Jul. 16, 2021

Product Category: Microcontrollers (MCU) >Digital Power Management IC

The MD6752 is a fully digital-controlled power supply IC, which incorporates a bridgeless PFC control circuit and an LLC current-resonant circuit. The PFC circuit, driven by continuous conduction mode (CCM), is controlled with frequencies suitable for applied input voltages and loads. The IC incorporates current mode for controlling constant voltages in the LLC stage and a floating drive circuit that drives an external high-side power MOSFET, in addition to functionally-rich protections. These digitally controlled strategies allow application-specific optimal settings. Compared to conventional analog control circuits, the IC can achieve more cost-effective, high-efficient, yet low-noise power systems with fewer external components.

Application

・Audiovisual Equipment

・Office Automation Equipment (e.g., Server, Multifunction Printer)

・Industrial Equipment

・Communication Equipment

other devices requiring high power switching supplies

Learn more
MD6752

600 V / 2.5, Sine-wave Driving, High Voltage 3-Phase BLDC Motor Driver [SIM2601MA]

Jun. 22, 2021

Product Category: ICs >Motor Drivers > High Voltage 3-phase Brushless DC Motor Drivers

The SIM2601MA is a high voltage 3-phase motor drivers driven by a sinusoidal control, which can support Hall element inputs, thus offering high-efficient yet low-noise motor control. Supplied in a highly heat-dissipating DIP package, where a controller, a gate driver, the output transistors of three phases, and bootstrap diodes are highly integrated, the SIM260xM series requires only a few external components for building a motor driver. This also allows a motor driver to be highly reliable in performance and design-friendly with its compactness. These products can optimally control the inverter systems of low- to medium-capacity motors that require universal input standards.

Application

• Fan Motor and Pump Motor for Washer and Dryer
• Fan Motor for Air Conditioner
• Fan Motor for Air Purifier and Electric Fan

Learn more
SIM2601MA  (In development)

600 V / 15 A, 3-phase BLDC Motor Driver IC [SCM1272MA]

Apr. 26, 2021

Product Category: ICs >Motor Drivers > High Voltage 3-phase Brushless DC Motor Drivers


The SCM1272MA is a high voltage 3-phase motor driver in which transistors, pre-drive circuits, and bootstrap diodes with current-limiting resistors are highly integrated. The product can run on a 3-shunt current detection system and optimally control the inverter systems of medium-capacity motors that require universal input standards.

Specifications

• Breakdown Voltage: 600 V
• Output Current: 15 A

Applications:
For motor drives such as:

• Refrigerator Compressor Motor
• Air Conditioner Compressor Motor
• Washing Machine Main Motor
• Fan Motor
• Pump Motor

Learn more 　
SCM1272MA

High-side Gate Driver IC
[SSC4S790]

Apr. 05, 2021

Product Category: ICs >Power Management ICs > Gate Drivers


SSC4S790 is a single channel high-side gate driver. The IC incorporates a floating drive circuit for a high-side power MOSFET, which can be used for a high-side gate driver such as a half-bridge converter or bridgeless PFC.
The IC is provided in the compact and low profile SOIC8 package.


Specification

• Power Supply Voltage, V_CC: 12 V to 18 V
• VGO Pin Peak Source Current: −300 mA
• VGO Pin Peak Sink Current: 550 mA

Application

• White Goods
• Office Automation Equipment
• Audio Visual Equipment
• Industrial Equipment
• Other Switched Mode Power Supply (SMPS)

Learn more
SSC4S790

Compact Surface Mount Type
Low Leakage Current [SJPE-L15, SJPE-T15]

Mar. 18, 2021

Product Category: Discretes >Diodes > Schottky Diodes

The SJPE series are Schottky diodes with allowing improvements in VF and IR characteristics. These characteristic features contribute to improving power supply efficiency and to enabling high-frequency systems.



Application

• DC-DC Converter
• Adapter

Learn More
150 V, 3.0 A　　SJPE-L15　
150 V, 5.0 A　　SJPE-T15　
　
　SJPE series Flyer

Power ICs for PWM Off-line Switching Power Supply
[STR6A100xV/xVD Series]

Mar. 16, 2021

Product Category: ICs >Power Management ICs > Off-line Converters

The STR6A100xV/xVD series are power ICs for switching power supplies, incorporating a MOSFET and a current mode PWM controller IC. The operating mode of the IC automatically changes to green-mode or burst oscillation mode according to load in order to improve the all load efficiency. The product achieves high cost-performance power supply systems with few external components.
STR6A153MVD, STR6A168HV, STR6A168HDV are the new addition to the series.



Application

• White Goods
• Office Automation Equipment
• Audio Visual Equipment
• Industrial Equipment
• Other Switched-Mode Power Supply

Learn more 　
PWM, 65kHz, Po=28W (650V/1.9Ω)　STR6A153MVD　
PWM, 100kHz, Po=14W (700V/10Ω)　STR6A168HV　
PWM, 100kHz, Po=14W (700V/10Ω)　STR6A168HVD

V_RM=150 V、 VF=0.90 V typ.
Schottky Diode [SPET-21015 、SPET21515]

Dec. 10, 2020

Product Category: Discretes >Diodes > Schottky Diodes

The SPET-21015 and SPET-21515 is a Schottky diode with a trench structure, allowing improvements in VF and IR characteristics. These characteristic features contribute to improving power supply efficiency and to enabling high-frequency systems.

Application
High speed switching applications as follows:

• DC/DC Converter
• Adapter

Learn more
SPET-21015
SPET-21515

Current Mode PWM Control
Automotive Off-line Converter [SFA0006A]

Dec. 04, 2020

Product Category: Automotive ICs >Automotive Power Management ICs > Automotive Off-line Converters

SFA0006A is the current mode PWM control IC with a primary-side regulation suitable for the automotive system controllers. By employing the primary-side regulation, the IC realizes low component counts and the downsizing the power supply circuit. For supporting the low consumption power and the low standby power, the IC has an automatic standby function. The IC automatically switches to the PWM mode in normal operation, and to the burst oscillation mode at standby. The IC achieves power supply systems to be more cost effective with fewer external components.

Specifications

• Maximum VCC Pin Voltage: 40 V
• DRV Pin Source Current (Peak): −270 mA
• DRV Pin Sink Current (Peak): 540 mA

Application
For following automotive switching power supply circuits connected to 12 V or 24 V battery:
• Auxiliary Power Supply
• Buck Converter Circuit


Learn more 　
SFA0006A


SFA0006A Flyer

650V / 50A , High Voltage 3-phase BLDC Motor Driver for Industrial [SAM265M50BS1]

Nov. 09, 2020

Product Category: ICs >Motor Drivers > High Voltage 3-phase Brushless DC Motor Drivers

The SAM265M50BS1 is a 3-phase brushless motor driver in which output transistors, a pre-drive circuit, bootstrap diodes with current-limiting resistors, and a temperature-sensing thermistor are highly integrated. The IC is suitable for driving 3-phase motor of the units such as industrial equipment.

Application

For driving 3-phase motors used in industrial equipment such as:
• Commercial Air Conditioner Compressor
• General-purpose Inverter
• Servomotor

Learn more 　
SAM265M50BS1


SAM2 Series Flyer

Fresh Food LED [SEP1FN1L89, SEP1YN1L72, SEP1YL1L72]

Oct. 14, 2020

Product Category: LEDs > Visible Light LEDs > Surface Mount Flat Type LEDs

These LEDs are specialized for lighting of food products such as food showcases.
The lineup includes three types of LEDs suited for fresh meat, fresh fish and produce (fruits and vegetables), and delicatessen.
The spectrum has been adjusted to naturally enhance the reddish tones of fresh meat and the silver scales of fresh fish, making the food appear fresher and more appetizing. Color reproducibility (color rendering) is also taken into consideration for fresh fish, produce, and delicatessen.
Customization is also possible upon request to achieve the desired color tone for each customer. Color matching which is difficult to quantify can also be supported, for instance, "emphasize reddish tones, and reduce bluish tones".

Features:

• Lineup of three types of LEDs that make each food item more appetizing: LEDs for "Meat", "Fresh Fish and Produce", "Delicatessen"
• Color rendering and presentation know-how backed by experience in the food industry to create colors with great satisfaction onsite.
• High reliability, made in Sanken's own factory in Japan

Application

• Lamps in Food Showcase
• Store Lighting　and more

Learn More:

80V/45A, Schottky Diodes for Automotives [SZ-E10EF48]

Oct. 12, 2020

Product Category: Discretes > Diodes > Schottky Diodes

The SZ-E10EF48 is a 80 V, 45 A Schottky diode for automotive applications.
The product achieves characteristics such as low leakage current and low forward voltage drop, thus providing a high-efficient rectification circuit. Its low thermal resistance package has excellent performance in heat dissipation.

Application

High speed switching applications such as:

• DC-DC Converter
• Adapter
• Secondary Rectifier Circuit

Learn more
SZ-E10EF48

LLC Current-Resonant
Off-Line Switching Controller [SSC3S932]

Oct. 01, 2020

Product Category: ICs > Power Management ICs > Off-line Converters

The SSC3S932 is a controller with SMZ* method for LLC current resonant switching power supplies, incorporating a floating drive circuit for a high-side power MOSFET. The product includes useful functions such as the automatic dead time adjustment and the capacitive mode detection. The product achieves high efficiency, low noise, and high cost-effective power supply systems with few external components.
*SMZ is the soft-switched multi-resonant zero current switch, and is achieved soft switching operation during all switching periods.

Application

Switching power supplies for electronic devices such as:

• Audio Visual (AV) Equipment
• Office Automation (OA)
• Industrial Apparatus
• Communication Facilities

Learn more
SSC3S932

4 Elements in a Compact Package, Automotive Discrete Module [SHD4111, SHD4115]

Sep. 29, 2020

Product Category: Automotive Discretes > Automotive Discrete Modules

The SHD4111 and SHD4115 are discrete modules enclosed in a small HSON-20 package.
The SHD4111 includes four elements (two fast recovery diodes, two N-channel power MOSFETs) and the SHD4115 includes four N-channel power MOSFETs.
The internal power MOSFETs have Zener diodes between gates and sources, thus requiring no externally clamped circuit for an injection coil drive circuit. Supplied in a low thermal resistance package, the product achieves high performance in heat dissipation. In addition, its HSON package employs a wettable flank structure, with the pin tips plated and the case resin around the pins grooved. This achieves higher reliability in mounting.

Application

• Injection Coil Driver Circuits

Learn more
SHD4111  (Single FRD×2, N-channel MOSFET×2 )
SHD4115  (N-channel MOSFET×4)

600 V / 2.5 to 5.0 A, Sine-wave Driving, High Voltage 3-Phase BLDC Motor Driver
[SIM2600M Series]

Jan. 15, 2020

Product Category: ICs >Motor Driver ICs > High Voltage > 3-Phase Brushless DC Motor Driver ICs

The SIM2600M series are high voltage 3-phase motor drivers driven by a sinusoidal control, which can support Hall element inputs, thus offering high-efficient yet low-noise motor control. Supplied in a highly heat-dissipating DIP package, where a controller, a gate driver, the output transistors of three phases, and bootstrap diodes are highly integrated, the SIM260xM series requires only a few external components for building a motor driver. This also allows a motor driver to be highly reliable in performance and design-friendly with its compactness. These products can optimally control the inverter systems of low- to medium-capacity motors that require universal input standards.

Application

• Fan Motor and Pump Motor for Washer and Dryer
• Fan Motor for Air Conditioner
• Fan Motor for Air Purifier and Electric Fan

Learn more
600 V, 2.5 A　SIM2601M (In development)
600V, 5.0 A　SIM2602M

150V/45A, Schottky Diodes for Automotives [SZ-E10ET415]

Dec. 06, 2019

Product Category: Discretes >Diodes > Schottky Diodes

The SZ-E10ET415 is a 150 V, 45 A Schottky diode for automotive applications. The product achieves characteristics such as low leakage current and low forward voltage drop, thus providing a high-efficient rectification circuit. Its low thermal resistance package has excellent performance in heat dissipation.

Application
High speed switching applications such as:

• DC/DC Converter
• Adapter
• Secondary Rectifier Circuit

Learn more
SZ-E10ET145

High Voltage 3-Phase BLDC Motor Driver With Sensorless Vector Control
[SX68200M Series]

Jul. 03, 2019

Product Category: ICs >Motor Driver ICs > High Voltage > 3-Phase Brushless DC Motor Driver ICs

The SX68200M series are 3-phase brushless motor drivers in which output transistors, pre-drive circuits, bootstrap diodes with current-limiting resistors are highly integrated. Employing a sinusoidal driving strategy with a sensorless vector control, the SX68200M series brings a small-sized, high-efficient, and low-noise motor controlling into your application. These products can run on a 3-shunt current detection system and optimally control the inverter systems of medium-capacity motors that require universal input standards.

Application
For motor drives such as:

• Fan Motor for Air Conditioner
• Fan Motor for Air Purifier and Electric Fan

Learn more
250V, 2.0A　SX68201M
600V, 1.5A　SX68203M
600V, 2.0A　SX68205M　(In development)

Supports Hall Element Input　600V, 1.5 to 2.0A
High Voltage 3-Phase BLDC Motor Driver [SX6812xM Series]

Jun. 28, 2019

Product Category: ICs >Motor Driver ICs > High Voltage > 3-Phase Brushless DC Motor Driver ICs

The SX6812xM series are high voltage 3-phase motor drivers driven by a sinusoidal control, which can support Hall element inputs, thus offering high-efficient yet low-noise motor control. Supplied in a thin SOP36 package, where a controller, a gate driver, the output transistors of three phases, and bootstrap diodes are highly integrated, the SX6812xM series requires only a few external components for building a motor driver circuit. This also allows a motor driver circuit to be highly reliable in performance and design-friendly with its compactness. These products can optimally control the inverter systems of low- to medium-capacity motors that require universal input standards.

Application
For motor drives such as:

• Fan Motor for Air Conditioner
• Fan Motor for Air Purifier and Electric Fan

Learn more
600V, 1.5A　SX68126M
600V, 2.0A　SX68127M (In Development)

High Voltage 3-Phase BLDC Motor Driver [SLA6846MH]

Apr. 09, 2019

Product Category： ICs ＞ Motor Driver ICs ＞ High Voltage ＞ 3-Phase Brushless DC Motor Driver ICs

The SLA6846MH is a high voltage 3-phase motor driver in which transistors and pre-drive circuits are highly integrated. Supplied in a ZIP24 package (heatsink type) with selectable leadforms, the SLA6846MH offers excellent mountability to a wide range of applications. The product can optimally control the inverter systems of low- to medium-capacity motors.

Application
For motor drives such as:

• Fan Motor and Pump Motor for Washer and Dryer
• Fan Motor for Air Conditioner
• Fan Motor for Air Purifier and Electric Fan

Learn more
SLA6846MH

The quasi-resonant switching power supply control IC
AC/DC Converter IC 【SSC1S312A】

Mar. 20, 2019

The quasi-resonant switching power supply control IC
AC/DC Converter IC 【SSC1S312A】 Product Category： ICs ＞ Power Management ICs ＞ AC/DC Converter ICs ＞ Controller

The IC incorporates a startup circuit and a standby function to reduce a power consumption and standby power.

Application

• Digital Appliance
• Office Automation (OA) Equipment
• White Goods
• Industrial Apparatus
• Communication Facilities

Features

• Soft-Start Function
• Adjustable Startup Voltage
• Maximum On-time Limitation Function
• Overvoltage Protection (OVP): Latched Shutdown
• Overload Protection (OLP): Latched Shutdown

Learn more:
SSC1S312A

IGBT with Zener diodes and gate resisters【DGU4020GR、DGU4520GR】

Feb. 14, 2019

Product Category: Discretes ＞ IGBTs

The DGU4020GR and DGU4520GR are IGBTs with Zener diodes and gate resisters, and achieve the ignition coil drive circuit without an external clamped circuit. These IGBTs have low saturation characteristic, and can improve the efficiency of the circuit.

Application

• Ignition Coil Driver Circuits

Features

• Complies with Automotive Quality Requirements
• Bare Lead Frame: Pb-free (RoHS Compliant)
• Low Saturation Voltage

Learn more:
DGU4020GR　 DGU4520GR

3-Phase Brushless Motor Driver ICs【SMA6860MH、SLA6860/70MH Series】

Dec. 12, 2018

Product Category： ICs ＞ Motor Driver ICs ＞ High Voltage ＞ 3-Phase Brushless DC Motor Driver ICs

The SLA6870MH and the SMA/SLA6860MH series are high voltage 3-phase motor driver ICs in which transistors, pre-driver ICs (MICs), and bootstrap circuits (diodes and resistors) are highly integrated. These products are enhanced the protection function from the products 6820 MH series.

Learn more

SMA6860MH SMA6862MH SMA6863MH
SMA6865MH SLA6868MH SLA6870MH

3-Phase Brushless DC Motor Driver ICs【SCM2007MKF、SCM2008MKF】

Nov. 26, 2018

Products： ICs ＞ Motor Driver ICs ＞ High Voltage ＞ 3-Phase Brushless DC Motor Driver ICs

The SCM2000MKF series are 3-phase brushless motor driver ICs.These products can run on a 3-shunt current detection system and optimally control the inverter systems of medium-capacity motors that require universal input standards.

Application

• Air Conditioner Compressor Motor

Features

• Bare Lead Frame: Pb-free (RoHS Compliant)
• Isolation Voltage: 2500V (for 1 min)
• Built-in Thermistor
• Built-in Bootstrap Diodes
• CMOS-compatible Input (3.3V or 5V
• Fault Signal Output at Protection Activation
• Shutdown Signal Input
• Selectable OCP Hold Time
  　(SELECT Pin: 34 µs, 8 ms) ・Protections Include:
  - Undervoltage Lockout for Power Supply
  　VBx Pin (UVLO_VB): Auto-restart
  　VCCx Pin (UVLO_VCCx): Auto-restart
  - Overcurrent Protection (OCP): Auto-restart
  - Overvoltage Protection (OVP): Auto-restart



Learn More
SCM2007MKF
SCM2008MKF

Fast Recovery Diode
【FMXR-1206S-CG、FMXR-4606S-SP、CTXR-5606S-SP】

Nov. 12, 2018

Product Category: Discretes ＞ Diodes ＞ Ultra-Fast-Recovery Rectifier Diodes (trr≦100ns)

FMXR-1206S-CG、FMXR-4606S-SP、CTXR-5606S-SP are fast recovery diodes. The low Qrr characteristic allows the product to have almost no ringing at turn-off, leading to the realization of low-noise systems.

Application

• For CCM PFC Circuit
• Secondary Side Rectifier Diode

Features

• Bare Lead Frame: Pb-free (RoHS Compliant)
• Low Noise
• Ultrafast

Learn More
FMXR-1206S-CG FMXR-4606S-SP CTXR-5606S-SP

The Compact and High Thermal Dissipation Packages
Discrete Module 【SHD4101, SHD4102】

Nov. 05, 2018

Products： Automotive ＞ Discrete Module

The packages of SHD4101 and SHD4102 are compact and slim HSON-20. These discrete module devices consolidate four TO252 class semiconductor elements into one package. These are compact, highly efficient, and reliable devices to be suitable for driving circuits of injection coils which are important parts of automobiles.

Features

• Suitable for high reliability applications
• Complying with automotive quality requirements
• AEC-Q101 qualified
• Pb-free bare lead frames: (RoHS compliant)
• Excellent heat dissipation packages
• No lead surface mount packages 11.9mm×9.1mm×1.5mm（HSON-20）


Learn more:
SHD4101 SHD4102

Single Channel Low-Side Gate Driver
Full of Protection Functions 【SSC4S701】

Oct. 09, 2018

Product Category： ICs ＞ Power Management ICs ＞ Gate Driver ICs

SSC4S701 is a single channel low-side gate driver, and drives a power transistor such as an IGBT and a power MOSFET. The IC has the undervoltage lockout for power supply and the overcurrent protection. When these protections are activated, the IC outputs the fault signal whose width is adjustable by an external capacitor. The IC is provided in the compact and low profile SOIC8 package.

Main characteristics

• Supply Voltage　Vｃｃ： 24 V（Recommended Value is 15 V）
• Output Source Current (Peak)： -0.8 A
• Output Sink Current (Peak)： 1.75 A

Features

• Single Input and Output
• Fault Signal Output at Abnormal Condition
• Protections
  　Undervoltage Lockout for Power Supply
  　Overcurrent Protection


Learn more:
SSC4S701

LLC Current-Resonant Controller IC with Built-in Full Protection Functions and External Power Supply【SSC3S931】

Sep. 06, 2018

Product Category: ICs ＞ Power Management ICs ＞ AC/DC Converter ICs ＞ Controller

SSC3S931 is an LLC current-resonant controller IC with an integrated floating drive circuit for a high-side power MOSFET. This highly integrated controller has an automatic adjustment of dead time and resonance loss detection function. This product will greatly simplify the system design and make configuring easier with cost-efficient, smaller, more efficient, and low noise power supply systems. In addition, by setting the standby power supply to external, this product will expend less standby power than before.
Learn more:
SSC3S931　

Chip LED New Package Items: 2 Series Added.
13 Flat Package LEDs Added.

Aug. 15, 2018

Product Category： LED ＞ Visible Light＞ChipLED

2 new series of packages were added to the small chip LED series (16 × 08 type).

• Dome lens SEC ××× 13C series
  　・・ Our 16×08-type dome shaped lens was adopted with the aim to increase
     brightness.
• 1608-type high profile type SEC ××× 11C series（H=1.06mm）
  　・・　the high-profile type H = 1.06 mm has been added to the current series
     (H = 0.55 mm and 0.7 mm line). You can select the LED that matches the exposure
     surface of the set. Light leakage has also been reduced.



Product Category： LED ＞ Visible Light＞Flat LED

We have added 13 varieties of different lightness and color to the current flat LED package.

Features:
RoHS compliant, compatible with heat resistance of lead-free soldering.
Ideal for application to automobiles, household appliances, office automation, and indicators.

VZ = 40 V (Typ.) the Alternator Diodes for Automotive
【SG-C17VLZ40S、SG-C17VLZ40R】

Jun. 05, 2018

Product Category: Automotive > Discretes > Diodes for Alternators

SG-C17VLZ40S and SG-C17VLZ40R are the rectification diodes designed for alternator circuit of automotives, and have zener characteristics with high surge capability.
They are provided in a press-fit type package that has high heat release capability, and high reliability for high temperature and humid environment. In addition, the bridge circuit can be configured easily in small area by using suffix “R” type and suffix “S” type of reverse polarity type. Suitable for alternator circuit for the 12V Battery Automotive.

Main Characteristics:

• VZ = 36V～43V
• IF(AV) = 50 A

Features：

• TJ = 235 °C Capability Suitable for High Reliability
• Thermal Fatigue Capability: 5,000 cyc.
• High Surge Capability
• RoHS Compliant

Learn More
SG-C17VLZ40R
SG-C17VLZ40S

High dissipation package realizing thermal resistance θj-c : 1.0℃/W!
High Voltage 3-phase Motor Driver IC for Autmotive [SAE6530P0DA01]

Mar. 28, 2018

Product Category: Automotive > Motor Driver ICs > 3-Phase Motor Driver ICs

SAE6530P0DA01 is a three- phase motor driver IC in which output switching devices, pre-driver ICs, bootstrap diode withcurrent limiting resistors, and thermistors for temperature detection are highly integrated. The IC is suitable for driving 3-phase motors in high voltage auxiliary systems.

• AEC-Q100 Qualified
• Bare Lead Frame: Pb-free (RoHS Compliant)
• High Thermal Dissipation DIP Package
      (Low Thermal Resistance, Rθ(j-c): 1.0 °C/W)
• Built-in Bootstrap Diodes
• Built-in 650 V IGBTs with Fast Recovery Diode
• Fault Signal Output at Protect Circuit Activated
• Protections
     Overcurrent Protection (OCP)
     Under Voltage Protection (UVLO）
• Built-in NTC Thermistor
• Isolation Voltage: 2500 V (for 1 min)　

Learn More

New Addition to the SIM6800M Series
IGBT Integrated High Voltage 3ph Motor Driver IC

Dec. 13, 2017

Product Category: ICs >Motor Driver ICs > High Voltage > 3-Phase Brushless DC Motor Driver ICs

The SIM6880M is a high voltage 3-phase motor driver IC in which transistors, a pre-driver IC (MIC), and bootstrap circuits (diodes and resistors) are highly integrated. The product can run on a 3-shunt current detection system and optimally control the inverter systems of small- to medium-capacity motors that require universal input standards.

Features:

• Built-in Bootstrap Diodes with Current Limiting Resistors (60 Ω)
• Fault Signal Output at Protection Activation (FO Pin)
• Various protections including Overcurrent Limit (OCL), Overcurrent Protection (OCP), Thermal Shutdown (TSD)

Application：

• Fan Motor and Pump Motor for Washer and Dryer
• Fan Motor for Air Conditioner, Air Purifier, and Electric Fan

Learn more:

SIM6880M

Low VF Rectifier Diode for Alternator
[SG-17VLEF]

Nov. 24, 2017

Product Category: Automotive > Discretes > Diodes for Alternators

SG-17VLEF is a rectification diode designed for alternator circuit of automotives, and has zener characteristics with high surge capability. They are provided in a press-fit type package.
SG-17VLEF achieves lower VF compared to the conventional product. This realizes improvement of output efficiency of the alternator, contributing to the development of fuel efficient vehicles. In addition, the bridge circuit can be configured easily in small area by using suffix “S” type and suffix “R” type of reverse polarity type.

Features:

• Io=50A
• VRM=17V

SG-17VLEFR
SG-17VLEFS
