High Voltage 3-Phase BLDC Motor Driver with Temperature Sensing Function
[SIM6890M Series]

Aug. 30, 2021

Products: ICs > Motor Drivers> Hight Voltage 3-phase Brushless DC Motor Drivers

The SIM6890M series are high voltage 3-phase motor drivers in which transistors, pre-drive circuits, and bootstrap circuits (diodes and resistors) are highly integrated. These products can optimally control the inverter systems of low- to medium-capacity motors that require universal input standards.

Remarks
SIM6890M series

Application
  • Refrigerator Compressor Motor
  • Fan Motor and Pump Motor for Washer and Dryer
  • Fan Motor for Air Conditioner
  • Fan Motor for Air Purifier

Lean more
SIM6891M
SIM6892M
SIM6893M
SIM6896M

Fully digital-controlled power supply IC【MD6752】 (incorporates a bridgeless PFC control circuit and an LLC current-resonant circuit)

Jul. 16, 2021

Product Category: Microcontrollers (MCU) >Digital Power Management IC

The MD6752 is a fully digital-controlled power supply IC, which incorporates a bridgeless PFC control circuit and an LLC current-resonant circuit. The PFC circuit, driven by continuous conduction mode (CCM), is controlled with frequencies suitable for applied input voltages and loads. The IC incorporates current mode for controlling constant voltages in the LLC stage and a floating drive circuit that drives an external high-side power MOSFET, in addition to functionally-rich protections. These digitally controlled strategies allow application-specific optimal settings. Compared to conventional analog control circuits, the IC can achieve more cost-effective, high-efficient, yet low-noise power systems with fewer external components.

Application

  • ・Audiovisual Equipment
  • ・Office Automation Equipment (e.g., Server, Multifunction Printer)
  • ・Industrial Equipment
  • ・Communication Equipment
  • other devices requiring high power switching supplies

    Learn more
    MD6752

    600 V / 2.5, Sine-wave Driving, High Voltage 3-Phase BLDC Motor Driver [SIM2601MA]

    Jun. 22, 2021

    Product Category: ICs >Motor Drivers > High Voltage 3-phase Brushless DC Motor Drivers

    The SIM2601MA is a high voltage 3-phase motor drivers driven by a sinusoidal control, which can support Hall element inputs, thus offering high-efficient yet low-noise motor control. Supplied in a highly heat-dissipating DIP package, where a controller, a gate driver, the output transistors of three phases, and bootstrap diodes are highly integrated, the SIM260xM series requires only a few external components for building a motor driver. This also allows a motor driver to be highly reliable in performance and design-friendly with its compactness. These products can optimally control the inverter systems of low- to medium-capacity motors that require universal input standards.

    Application

    • Fan Motor and Pump Motor for Washer and Dryer
    • Fan Motor for Air Conditioner
    • Fan Motor for Air Purifier and Electric Fan

    Learn more
    SIM2601MA  (In development)

    600 V / 15 A, 3-phase BLDC Motor Driver IC [SCM1272MA]

    Apr. 26, 2021

    Product Category: ICs >Motor Drivers > High Voltage 3-phase Brushless DC Motor Drivers


    The SCM1272MA is a high voltage 3-phase motor driver in which transistors, pre-drive circuits, and bootstrap diodes with current-limiting resistors are highly integrated. The product can run on a 3-shunt current detection system and optimally control the inverter systems of medium-capacity motors that require universal input standards.


    Specifications
    • Breakdown Voltage: 600 V
    • Output Current: 15 A

    Applications:
    For motor drives such as:
    • Refrigerator Compressor Motor
    • Air Conditioner Compressor Motor
    • Washing Machine Main Motor
    • Fan Motor
    • Pump Motor

    Learn more
    SCM1272MA

    High-side Gate Driver IC
    [SSC4S790]

    Apr. 05, 2021

    Product Category: ICs >Power Management ICs > Gate Drivers


    SSC4S790 is a single channel high-side gate driver. The IC incorporates a floating drive circuit for a high-side power MOSFET, which can be used for a high-side gate driver such as a half-bridge converter or bridgeless PFC.
    The IC is provided in the compact and low profile SOIC8 package.


    Specification

    • Power Supply Voltage, VCC: 12 V to 18 V
    • VGO Pin Peak Source Current: −300 mA
    • VGO Pin Peak Sink Current: 550 mA

    Application
    • White Goods
    • Office Automation Equipment
    • Audio Visual Equipment
    • Industrial Equipment
    • Other Switched Mode Power Supply (SMPS)

    Learn more
    SSC4S790

    Compact Surface Mount Type
    Low Leakage Current [SJPE-L15, SJPE-T15]

    Mar. 18, 2021

    Product Category: Discretes >Diodes > Schottky Diodes

    The SJPE series are Schottky diodes with allowing improvements in VF and IR characteristics. These characteristic features contribute to improving power supply efficiency and to enabling high-frequency systems.

    diode specification

    Application

    • DC-DC Converter
    • Adapter


    Learn More
    150 V, 3.0 A  SJPE-L15
    150 V, 5.0 A  SJPE-T15

    pdf SJPE series Flyer

    Power ICs for PWM Off-line Switching Power Supply
    [STR6A100xV/xVD Series]

    Mar. 16, 2021

    Product Category: ICs >Power Management ICs > Off-line Converters

    The STR6A100xV/xVD series are power ICs for switching power supplies, incorporating a MOSFET and a current mode PWM controller IC. The operating mode of the IC automatically changes to green-mode or burst oscillation mode according to load in order to improve the all load efficiency. The product achieves high cost-performance power supply systems with few external components.
    STR6A153MVD, STR6A168HV, STR6A168HDV are the new addition to the series.

    STR6A series lineup

    Application

    • White Goods
    • Office Automation Equipment
    • Audio Visual Equipment
    • Industrial Equipment
    • Other Switched-Mode Power Supply

    Learn more
    PWM, 65kHz, Po=28W (650V/1.9Ω) STR6A153MVD
    PWM, 100kHz, Po=14W (700V/10Ω) STR6A168HV
    PWM, 100kHz, Po=14W (700V/10Ω) STR6A168HVD

    VRM=150 V、 VF=0.90 V typ.
    Schottky Diode [SPET-21015 、SPET21515]

    Dec. 10, 2020

    Product Category: Discretes >Diodes > Schottky Diodes

    The SPET-21015 and SPET-21515 is a Schottky diode with a trench structure, allowing improvements in VF and IR characteristics. These characteristic features contribute to improving power supply efficiency and to enabling high-frequency systems.

    Features
    • Bare Lead Frame: Pb-free (RoHS Compliant)
    • Flammability: Equivalent to UL94V-0

      VRM IF(AV) VF (IF=5 A)
     SPET-21015 150 V 10 A 0.90 V typ.
     SPET-21515 150 V 15 A 0.90 V typ.

    Application
    High speed switching applications as follows:

    • DC/DC Converter
    • Adapter

    Learn more
    SPET-21015
    SPET-21515

    Current Mode PWM Control
    Automotive Off-line Converter [SFA0006A]

    Dec. 04, 2020

    Product Category: Automotive ICs >Automotive Power Management ICs > Automotive Off-line Converters

    SFA0006A is the current mode PWM control IC with a primary-side regulation suitable for the automotive system controllers. By employing the primary-side regulation, the IC realizes low component counts and the downsizing the power supply circuit. For supporting the low consumption power and the low standby power, the IC has an automatic standby function. The IC automatically switches to the PWM mode in normal operation, and to the burst oscillation mode at standby. The IC achieves power supply systems to be more cost effective with fewer external components.

    Specifications

    • Maximum VCC Pin Voltage: 40 V
    • DRV Pin Source Current (Peak): −270 mA
    • DRV Pin Sink Current (Peak): 540 mA

    • Application
      For following automotive switching power supply circuits connected to 12 V or 24 V battery:

      • Auxiliary Power Supply
      • Buck Converter Circuit


      Learn more
      SFA0006A


      pdf SFA0006A Flyer

    650V / 50A , High Voltage 3-phase BLDC Motor Driver for Industrial [SAM265M50BS1]

    Nov. 09, 2020

    Product Category: ICs >Motor Drivers > High Voltage 3-phase Brushless DC Motor Drivers

    The SAM265M50BS1 is a 3-phase brushless motor driver in which output transistors, a pre-drive circuit, bootstrap diodes with current-limiting resistors, and a temperature-sensing thermistor are highly integrated. The IC is suitable for driving 3-phase motor of the units such as industrial equipment.


    Application
      For driving 3-phase motors used in industrial equipment such as:
    • Commercial Air Conditioner Compressor
    • General-purpose Inverter
    • Servomotor

    Learn more
    SAM265M50BS1


    pdf SAM2 Series Flyer

    Fresh Food LED [SEP1FN1L89, SEP1YN1L72, SEP1YL1L72]

    Oct. 14, 2020

    Product Category: LEDs > Visible Light LEDs > Surface Mount Flat Type LEDs

    These LEDs are specialized for lighting of food products such as food showcases.
    The lineup includes three types of LEDs suited for fresh meat, fresh fish and produce (fruits and vegetables), and delicatessen.
    The spectrum has been adjusted to naturally enhance the reddish tones of fresh meat and the silver scales of fresh fish, making the food appear fresher and more appetizing. Color reproducibility (color rendering) is also taken into consideration for fresh fish, produce, and delicatessen.
    Customization is also possible upon request to achieve the desired color tone for each customer. Color matching which is difficult to quantify can also be supported, for instance, "emphasize reddish tones, and reduce bluish tones".


    Features:
    • Lineup of three types of LEDs that make each food item more appetizing: LEDs for "Meat", "Fresh Fish and Produce", "Delicatessen"
    • Color rendering and presentation know-how backed by experience in the food industry to create colors with great satisfaction onsite.
    • High reliability, made in Sanken's own factory in Japan


    Spectrum comparison of Sanken LED for meat and general lighting LED

    Application
    • Lamps in Food Showcase
    • Store Lighting and more

    Learn More:
    LED for Meat SEP1FN1L89 (Under Development)
    LED for Fresh Fish and Produce   SEP1YN1L72 (Under Development)
    LED for Delicatessen SEP1YL1L72 (Under Development)


    80V/45A, Schottky Diodes for Automotives [SZ-E10EF48]

    Oct. 12, 2020

    Product Category: Discretes > Diodes > Schottky Diodes

    The SZ-E10EF48 is a 80 V, 45 A Schottky diode for automotive applications.
    The product achieves characteristics such as low leakage current and low forward voltage drop, thus providing a high-efficient rectification circuit. Its low thermal resistance package has excellent performance in heat dissipation.

    Application

    High speed switching applications such as:
    • DC-DC Converter
    • Adapter
    • Secondary Rectifier Circuit

    Learn more
    SZ-E10EF48

    LLC Current-Resonant
    Off-Line Switching Controller [SSC3S932]

    Oct. 01, 2020

    Product Category: ICs > Power Management ICs > Off-line Converters

    The SSC3S932 is a controller with SMZ* method for LLC current resonant switching power supplies, incorporating a floating drive circuit for a high-side power MOSFET. The product includes useful functions such as the automatic dead time adjustment and the capacitive mode detection. The product achieves high efficiency, low noise, and high cost-effective power supply systems with few external components.
    *SMZ is the soft-switched multi-resonant zero current switch, and is achieved soft switching operation during all switching periods.

    Application

    Switching power supplies for electronic devices such as:
    • Audio Visual (AV) Equipment
    • Office Automation (OA)
    • Industrial Apparatus
    • Communication Facilities

    Learn more
    SSC3S932

    4 Elements in a Compact Package, Automotive Discrete Module [SHD4111, SHD4115]

    Sep. 29, 2020

    Product Category: Automotive Discretes > Automotive Discrete Modules

    The SHD4111 and SHD4115 are discrete modules enclosed in a small HSON-20 package.
    The SHD4111 includes four elements (two fast recovery diodes, two N-channel power MOSFETs) and the SHD4115 includes four N-channel power MOSFETs.
    The internal power MOSFETs have Zener diodes between gates and sources, thus requiring no externally clamped circuit for an injection coil drive circuit. Supplied in a low thermal resistance package, the product achieves high performance in heat dissipation. In addition, its HSON package employs a wettable flank structure, with the pin tips plated and the case resin around the pins grooved. This achieves higher reliability in mounting.

    Application

    • Injection Coil Driver Circuits

    Learn more
    SHD4111  (Single FRD×2, N-channel MOSFET×2 )
    SHD4115  (N-channel MOSFET×4)

    600 V / 2.5 to 5.0 A, Sine-wave Driving, High Voltage 3-Phase BLDC Motor Driver
    [SIM2600M Series]

    Jan. 15, 2020

    Product Category: ICs >Motor Driver ICs > High Voltage > 3-Phase Brushless DC Motor Driver ICs

    The SIM2600M series are high voltage 3-phase motor drivers driven by a sinusoidal control, which can support Hall element inputs, thus offering high-efficient yet low-noise motor control. Supplied in a highly heat-dissipating DIP package, where a controller, a gate driver, the output transistors of three phases, and bootstrap diodes are highly integrated, the SIM260xM series requires only a few external components for building a motor driver. This also allows a motor driver to be highly reliable in performance and design-friendly with its compactness. These products can optimally control the inverter systems of low- to medium-capacity motors that require universal input standards.

    Application

    • Fan Motor and Pump Motor for Washer and Dryer
    • Fan Motor for Air Conditioner
    • Fan Motor for Air Purifier and Electric Fan
    Learn more
    600 V, 2.5 A SIM2601M (In development)
    600V, 5.0 A SIM2602M

    150V/45A, Schottky Diodes for Automotives [SZ-E10ET415]

    Dec. 06, 2019

    Product Category: Discretes >Diodes > Schottky Diodes

    The SZ-E10ET415 is a 150 V, 45 A Schottky diode for automotive applications. The product achieves characteristics such as low leakage current and low forward voltage drop, thus providing a high-efficient rectification circuit. Its low thermal resistance package has excellent performance in heat dissipation.

    Application
    High speed switching applications such as:

    • DC/DC Converter
    • Adapter
    • Secondary Rectifier Circuit
    Learn more
    SZ-E10ET145

    High Voltage 3-Phase BLDC Motor Driver With Sensorless Vector Control
    [SX68200M Series]

    Jul. 03, 2019

    Product Category: ICs >Motor Driver ICs > High Voltage > 3-Phase Brushless DC Motor Driver ICs

    The SX68200M series are 3-phase brushless motor drivers in which output transistors, pre-drive circuits, bootstrap diodes with current-limiting resistors are highly integrated. Employing a sinusoidal driving strategy with a sensorless vector control, the SX68200M series brings a small-sized, high-efficient, and low-noise motor controlling into your application. These products can run on a 3-shunt current detection system and optimally control the inverter systems of medium-capacity motors that require universal input standards.

    Application
    For motor drives such as:

    • Fan Motor for Air Conditioner
    • Fan Motor for Air Purifier and Electric Fan
    Learn more
    250V, 2.0A SX68201M
    600V, 1.5A SX68203M
    600V, 2.0A SX68205M (In development)

    Supports Hall Element Input 600V, 1.5 to 2.0A
    High Voltage 3-Phase BLDC Motor Driver [SX6812xM Series]

    Jun. 28, 2019

    Product Category: ICs >Motor Driver ICs > High Voltage > 3-Phase Brushless DC Motor Driver ICs

    The SX6812xM series are high voltage 3-phase motor drivers driven by a sinusoidal control, which can support Hall element inputs, thus offering high-efficient yet low-noise motor control. Supplied in a thin SOP36 package, where a controller, a gate driver, the output transistors of three phases, and bootstrap diodes are highly integrated, the SX6812xM series requires only a few external components for building a motor driver circuit. This also allows a motor driver circuit to be highly reliable in performance and design-friendly with its compactness. These products can optimally control the inverter systems of low- to medium-capacity motors that require universal input standards.

    Application
    For motor drives such as:

    • Fan Motor for Air Conditioner
    • Fan Motor for Air Purifier and Electric Fan

    Learn more
    600V, 1.5A SX68126M
    600V, 2.0A SX68127M (In Development)

    High Voltage 3-Phase BLDC Motor Driver [SLA6846MH]

    Apr. 09, 2019

    Product Category: ICs > Motor Driver ICs > High Voltage > 3-Phase Brushless DC Motor Driver ICs

    The SLA6846MH is a high voltage 3-phase motor driver in which transistors and pre-drive circuits are highly integrated. Supplied in a ZIP24 package (heatsink type) with selectable leadforms, the SLA6846MH offers excellent mountability to a wide range of applications. The product can optimally control the inverter systems of low- to medium-capacity motors.

    Application
    For motor drives such as:

    • Fan Motor and Pump Motor for Washer and Dryer
    • Fan Motor for Air Conditioner
    • Fan Motor for Air Purifier and Electric Fan

    Learn more
    SLA6846MH

    The quasi-resonant switching power supply control IC
    AC/DC Converter IC 【SSC1S312A】

    Mar. 20, 2019

    The quasi-resonant switching power supply control IC
    AC/DC Converter IC 【SSC1S312A】 Product Category: ICs > Power Management ICs > AC/DC Converter ICs > Controller

    The IC incorporates a startup circuit and a standby function to reduce a power consumption and standby power.

    Application

    • Digital Appliance
    • Office Automation (OA) Equipment
    • White Goods
    • Industrial Apparatus
    • Communication Facilities

    Features
    • Soft-Start Function
    • Adjustable Startup Voltage
    • Maximum On-time Limitation Function
    • Overvoltage Protection (OVP): Latched Shutdown
    • Overload Protection (OLP): Latched Shutdown

    Learn more:
    SSC1S312A

    IGBT with Zener diodes and gate resisters【DGU4020GR、DGU4520GR】

    Feb. 14, 2019

    Product Category: Discretes > IGBTs

    The DGU4020GR and DGU4520GR are IGBTs with Zener diodes and gate resisters, and achieve the ignition coil drive circuit without an external clamped circuit. These IGBTs have low saturation characteristic, and can improve the efficiency of the circuit.

    Application

    • Ignition Coil Driver Circuits
    Features
    • Complies with Automotive Quality Requirements
    • Bare Lead Frame: Pb-free (RoHS Compliant)
    • Low Saturation Voltage

    Learn more:
    DGU4020GR  DGU4520GR

    3-Phase Brushless Motor Driver ICs【SMA6860MH、SLA6860/70MH Series】

    Dec. 12, 2018

    Product Category: ICs > Motor Driver ICs > High Voltage > 3-Phase Brushless DC Motor Driver ICs

    The SLA6870MH and the SMA/SLA6860MH series are high voltage 3-phase motor driver ICs in which transistors, pre-driver ICs (MICs), and bootstrap circuits (diodes and resistors) are highly integrated. These products are enhanced the protection function from the products 6820 MH series.

    Learn more

    SMA6860MH SMA6862MH SMA6863MH
    SMA6865MH SLA6868MH SLA6870MH

    3-Phase Brushless DC Motor Driver ICs【SCM2007MKF、SCM2008MKF】

    Nov. 26, 2018

    Products: ICs > Motor Driver ICs > High Voltage > 3-Phase Brushless DC Motor Driver ICs

    The SCM2000MKF series are 3-phase brushless motor driver ICs.These products can run on a 3-shunt current detection system and optimally control the inverter systems of medium-capacity motors that require universal input standards.

    Application

    • Air Conditioner Compressor Motor
    Features
    • Bare Lead Frame: Pb-free (RoHS Compliant)
    • Isolation Voltage: 2500V (for 1 min)
    • Built-in Thermistor
    • Built-in Bootstrap Diodes
    • CMOS-compatible Input (3.3V or 5V
    • Fault Signal Output at Protection Activation
    • Shutdown Signal Input
    • Selectable OCP Hold Time
       (SELECT Pin: 34 µs, 8 ms) ・Protections Include:
      - Undervoltage Lockout for Power Supply
       VBx Pin (UVLO_VB): Auto-restart
       VCCx Pin (UVLO_VCCx): Auto-restart
      - Overcurrent Protection (OCP): Auto-restart
      - Overvoltage Protection (OVP): Auto-restart

    Learn More
    SCM2007MKF
    SCM2008MKF

    Fast Recovery Diode
    【FMXR-1206S-CG、FMXR-4606S-SP、CTXR-5606S-SP】

    Nov. 12, 2018

    Product Category: Discretes > Diodes > Ultra-Fast-Recovery Rectifier Diodes (trr≦100ns)

    FMXR-1206S-CG、FMXR-4606S-SP、CTXR-5606S-SP are fast recovery diodes. The low Qrr characteristic allows the product to have almost no ringing at turn-off, leading to the realization of low-noise systems.

    Application

    • For CCM PFC Circuit
    • Secondary Side Rectifier Diode

    Features
    • Bare Lead Frame: Pb-free (RoHS Compliant)
    • Low Noise
    • Ultrafast

    Learn More
    FMXR-1206S-CG FMXR-4606S-SP CTXR-5606S-SP

    The Compact and High Thermal Dissipation Packages
    Discrete Module 【SHD4101, SHD4102】

    Nov. 05, 2018

    Products: Automotive > Discrete Module

    The packages of SHD4101 and SHD4102 are compact and slim HSON-20. These discrete module devices consolidate four TO252 class semiconductor elements into one package. These are compact, highly efficient, and reliable devices to be suitable for driving circuits of injection coils which are important parts of automobiles.

    Features

    • Suitable for high reliability applications
    • Complying with automotive quality requirements
    • AEC-Q101 qualified
    • Pb-free bare lead frames: (RoHS compliant)
    • Excellent heat dissipation packages
    • No lead surface mount packages 11.9mm×9.1mm×1.5mm(HSON-20)
       SHD4101_SHD4102_figure
    Learn more:
    SHD4101 SHD4102

    Single Channel Low-Side Gate Driver
    Full of Protection Functions 【SSC4S701】

    Oct. 09, 2018

    Product Category: ICs > Power Management ICs > Gate Driver ICs

    SSC4S701 is a single channel low-side gate driver, and drives a power transistor such as an IGBT and a power MOSFET. The IC has the undervoltage lockout for power supply and the overcurrent protection. When these protections are activated, the IC outputs the fault signal whose width is adjustable by an external capacitor. The IC is provided in the compact and low profile SOIC8 package.

    Main characteristics

    • Supply Voltage Vcc: 24 V(Recommended Value is 15 V)
    • Output Source Current (Peak): -0.8 A
    • Output Sink Current (Peak): 1.75 A

    Features
    • Single Input and Output
    • Fault Signal Output at Abnormal Condition
    • Protections
       Undervoltage Lockout for Power Supply
       Overcurrent Protection

    Learn more:
    SSC4S701

    LLC Current-Resonant Controller IC with Built-in Full Protection Functions and External Power Supply【SSC3S931】

    Sep. 06, 2018

    Product Category: ICs > Power Management ICs > AC/DC Converter ICs > Controller

    SSC3S931 is an LLC current-resonant controller IC with an integrated floating drive circuit for a high-side power MOSFET. This highly integrated controller has an automatic adjustment of dead time and resonance loss detection function. This product will greatly simplify the system design and make configuring easier with cost-efficient, smaller, more efficient, and low noise power supply systems. In addition, by setting the standby power supply to external, this product will expend less standby power than before.
    Learn more:
    SSC3S931

    Chip LED New Package Items: 2 Series Added.
    13 Flat Package LEDs Added.

    Aug. 15, 2018

    Product Category: LED > Visible Light>ChipLED

    2 new series of packages were added to the small chip LED series (16 × 08 type).

    • Dome lens SEC ××× 13C series
       ・・ Our 16×08-type dome shaped lens was adopted with the aim to increase
         brightness.
    • 1608-type high profile type SEC ××× 11C series(H=1.06mm)
       ・・ the high-profile type H = 1.06 mm has been added to the current series
         (H = 0.55 mm and 0.7 mm line). You can select the LED that matches the exposure
         surface of the set. Light leakage has also been reduced.
       dome_figure

    Product Category: LED > Visible Light>Flat LED

    We have added 13 varieties of different lightness and color to the current flat LED package.

    Features:
    RoHS compliant, compatible with heat resistance of lead-free soldering.
    Ideal for application to automobiles, household appliances, office automation, and indicators.

    VZ = 40 V (Typ.) the Alternator Diodes for Automotive
    【SG-C17VLZ40S、SG-C17VLZ40R】

    Jun. 05, 2018

    Product Category: Automotive > Discretes > Diodes for Alternators

    SG-C17VLZ40S and SG-C17VLZ40R are the rectification diodes designed for alternator circuit of automotives, and have zener characteristics with high surge capability.
    They are provided in a press-fit type package that has high heat release capability, and high reliability for high temperature and humid environment. In addition, the bridge circuit can be configured easily in small area by using suffix “R” type and suffix “S” type of reverse polarity type. Suitable for alternator circuit for the 12V Battery Automotive.

    Main Characteristics:

    • VZ = 36V~43V
    • IF(AV) = 50 A

    Features:
    • TJ = 235 °C Capability Suitable for High Reliability
    • Thermal Fatigue Capability: 5,000 cyc.
    • High Surge Capability
    • RoHS Compliant

    Learn More
    SG-C17VLZ40R
    SG-C17VLZ40S

    High dissipation package realizing thermal resistance θj-c : 1.0℃/W!
    High Voltage 3-phase Motor Driver IC for Autmotive [SAE6530P0DA01]

    Mar. 28, 2018

    Product Category: Automotive > Motor Driver ICs > 3-Phase Motor Driver ICs

    SAE6530P0DA01 is a three- phase motor driver IC in which output switching devices, pre-driver ICs, bootstrap diode withcurrent limiting resistors, and thermistors for temperature detection are highly integrated. The IC is suitable for driving 3-phase motors in high voltage auxiliary systems.


    • AEC-Q100 Qualified
    • Bare Lead Frame: Pb-free (RoHS Compliant)
    • High Thermal Dissipation DIP Package
          (Low Thermal Resistance, Rθ(j-c): 1.0 °C/W)
    • Built-in Bootstrap Diodes
    • Built-in 650 V IGBTs with Fast Recovery Diode
    • Fault Signal Output at Protect Circuit Activated
    • Protections
         Overcurrent Protection (OCP)
         Under Voltage Protection (UVLO)
    • Built-in NTC Thermistor
    • Isolation Voltage: 2500 V (for 1 min)

    Learn More

    New Addition to the SIM6800M Series
    IGBT Integrated High Voltage 3ph Motor Driver IC

    Dec. 13, 2017

    Product Category: ICs >Motor Driver ICs > High Voltage > 3-Phase Brushless DC Motor Driver ICs

    The SIM6880M is a high voltage 3-phase motor driver IC in which transistors, a pre-driver IC (MIC), and bootstrap circuits (diodes and resistors) are highly integrated. The product can run on a 3-shunt current detection system and optimally control the inverter systems of small- to medium-capacity motors that require universal input standards.

    Features:

    • Built-in Bootstrap Diodes with Current Limiting Resistors (60 Ω)
    • Fault Signal Output at Protection Activation (FO Pin)
    • Various protections including Overcurrent Limit (OCL), Overcurrent Protection (OCP), Thermal Shutdown (TSD)

    Application:

    • Fan Motor and Pump Motor for Washer and Dryer
    • Fan Motor for Air Conditioner, Air Purifier, and Electric Fan


    Learn more:

    SIM6880M

    Low VF Rectifier Diode for Alternator
    [SG-17VLEF]

    Nov. 24, 2017

    Product Category: Automotive > Discretes > Diodes for Alternators

    SG-17VLEF is a rectification diode designed for alternator circuit of automotives, and has zener characteristics with high surge capability. They are provided in a press-fit type package.
    SG-17VLEF achieves lower VF compared to the conventional product. This realizes improvement of output efficiency of the alternator, contributing to the development of fuel efficient vehicles. In addition, the bridge circuit can be configured easily in small area by using suffix “S” type and suffix “R” type of reverse polarity type.

    Features:

    • Io=50A
    • VRM=17V
    SG-17VLEFR
    SG-17VLEFS

    Questions or Comments?

    Please feel free to contact us if you cannot find the desired product from the lineup.
